Box Gauge

The Box Gauge is a precision Go / No-Go inspection gauge used for checking overall dimensions, width, height, or step features of machined components. It is designed to allow fast and repeatable pass/fail inspection in production environments, eliminating the need for time-consuming measurement readings.

Manufactured by P.S. & SONS from high-grade tool steel, Box Gauges are precision-ground and rigidly constructed to ensure excellent accuracy, stability, and long service life. The sturdy base and fixed inspection faces provide consistent reference points, making the gauge ideal for shop-floor and quality control use.

Key Features

• Go / No-Go type dimensional inspection

• High rigidity for stable and repeatable results

• Precision-ground measuring surfaces

• Clear size and tolerance identification

• Designed for continuous production inspection

Applications

• Automotive and engineering components

• Machine shops and production units

• Quality control and inspection departments

• Precision manufacturing industries

P.S. & SONS manufactures Box Gauges in standard and fully customized designs, as per customer drawings and inspection requirements, ensuring reliable dimensional control for domestic and export markets.
